Folding Machine Spare Parts



FOLDING MACHINE SPARE PARTS


We always have following Spares of Folding Machine readily available from Stock:



FOLDING MACHINE SPARE PARTS FOLDING MACHINE SPARE PARTS FOLDING MACHINE SPARE PARTS

         Part No.     DESCRIPTION



1.          1          Main Side Wall (RH & LH)

2.          1a         Rods for Main side wall

3.            2         Triangular frame

     4.           2a       Screw for adjusting triangular Frame

     5.           3         Double Folding Back side frame (LW & RH)

6.            3a       CI Bracket  for above

7.            4         Plating  Platform side Wall RH & LH

8.            5         Rack

9.            5a       Rack Boss

10.        6         Folding Blade Gu8ide Rod

11.        7         Cam Lever Rod

12.        8         Rack Cover

13.        8a       Bearing  Boss

14.        9         Foot Pedal

15.        10       Wall Pillar for Double  Folding  Attachment

16.        11       Cham  guard cover

17.        12       Arm Lever

18.        13       Cam Lever

19.        14       Cam Lever Spring

20.        14a     Cam lever Spring Bolt

21.        15       Double Folding Attachment 2- guide

22.        16       Cone Pulley Belt Moving Bracket

23.        17       Loose Fast Pulley

24.        18       Woolen  Rolls Pulley  10- dia

25.        19       Weight Box  Chain Half Cut  Eccentric

26.        20       Tie Rod Flange

27.        21       40 T Chain Wheel Flange

28.        22       Loose Fast Lever LH & RH

29.        23       Eccentric

30.        24       Platform stopping handle

31.        25       Cloth Adjustment Hand Operating Handle

32.        26       40T Chain Wheel half inch pitch

33.        27       Plaiting Platform Double Groove Chain  Pulley

34.        28       Folding Fillet  (Canvas mounting 1 mtr long)

35.        29       Folding  Blade (Rate per inch)

36.        30       Loose Fast Lever Attachment collecting  Rod with boss

37.        31       Loose Fast ever Handle Back

38.        32       Loose Fast          Lever Fornt

39.        33       Loose Fast Lever Attachment Bracket

40.        34a     Pin for lever attachment stopping bkt

41.        35       Triangular Frame Rod Bracket

42.        36       Double Folding Attachment  Screw Bkt

43.        37       Guide Roll Bracket

44.        37a     Guide Roll Bracket shaft

45.        38       Guide Roll Bracket Spring

46.        38a     Bolt for Guide Roll  Bracket

47.        39       Spring Bracket

48.        40       Arm Bracket

49.        41       Triangular Frame Bracket

50.        42       Hand Operating Bracket

51.        42a     Shaft for above

52.        43       Wooden Platform Pillar

53.        44       Triangular Frame Rod Bracket

54.        45       Cam Lever Boul Pin

55.        46       Cam Lever Boul

56.        47       Single Folding Platform Bracket

57.        48       Single Folding Roll Bracket

58.        49       Folding  fillel pedestal Nut

59.        49a     Backlite Boul for above

60.        50       Small Stinge  Pully Boss

61.        50a     Bracket  for above

    62.         51       Canvan Bell Bracket

    63.          52       Arm Lever Boul with bolt

    64.          52a     Arm Lever Boul with bolt

    65.          53       Loose Bush or Ball Bearing

    66.          54       Triangular Frame Nut

    67.           55       Guide Rod Eccentric

    68.           56       Chain Bracket

    69.           57       Guide Roll Bracket

    70.            57a     Pin for Guide Rod Bracket

    71.             58      Roll Bracket

    72.             59      Guide Roll Bracket

    73.             60      Rachet Wheel

    74.             60a    Pin for Rachet Wheel

    75.             61      Small String Pulley

    76.             62      Single  Groove Chain Pulley

    77.             63      Stringe Pulley Boss

    78.             64      Small Stringe Pulley

    79.             65      Hand Wheel

    80.             65a    Hand Wheel for Wollen Roll 1 - hole

    81.             65b    Hand Wheel for Woolen Roll 1- hole

    82.             65c    Hand Wheel for Single End Screw - -hole

    83.             66      Small Hand  Wheel

    84.             67      Single Folding Platform Hand Wheel

    85.             68      Cloth Guide Flange

    86.             69      Rachet  Wheel

    87.             70      12T Chain Wheel - - hole

    88.             71      12T Chain Wheel 1- hole

    89.             72      Main Shaft 20T pinion 1.1/4 - hole

    90.             73      Rack 20T Pinion 30mm hole

    91.             74      Double Folding Att. Guide Roll Bracket

    92.             75      Rack Boss Bush

    93.             76      Bkt. for Guide Roll Bkt (P.No.37)

    94.             77      Cam Lever Collet -- hole

    95.             78      Main Shaft Collet 40mm hole

    96.             79      Plaiting Platform Rolling Pulley

    97.             80      Batch Roll Pulley

    98.             80a    Pin Bar  above

    99.             81      Wall Boss Bearing covey

   100.           82      Double Grow Pulley for Plaiting P L Form

   101.           83      Single Grooved -do- do

   102.           84      Side Wall Bearing Boss RH & LH

   103.           85      Band Wheel

   104.           86      Folding Blade Bracket

   105.           87      Nylon Bush (big or small)

   106.           88      Cone Pulley

   107.           89      Single Folding  Cloth Guide for 2Pana

   108.           90      Weight Lifting Chain for Platform

   109.           91      Steel Roller Chain Wheel Guard Cover

   110.           92      Weight Box Chain  with pin & nut

   111.           93      Back Side Chain Wheel Guard Cover

   112.           94      Front Side Chain Wheel Guard Cover

   113.           95      Cam Lever  Spring

   114.           95a    Cam Lever Spring  Pin

   115.           96      Folding Blade Ball Bearing Pin

   116.           97      RackTee Boss Pin

   117.           97a    MS Washer for above

   118.           98      Rack Gear Screw

   119.           99      Folding Fillet  Pedestal Boll

   120.        101     Small Stringe Pulley Pin

   121.        103     Small Hand Wheel Pin

122.       103a    Tie Rod Flange Pin

123.       104      Single Groove Chain Pulley Pin

124.       107      150 T Rack Gear Wheel

125.       108      Double Folding Attachment Bkt (Ih & rh)

126.       110      Weight Box (65- machine

127.       --      Weight Box for 72- machine

128.       110      Weight Box for 80- machine

129.       111      Weight (PER EACH)

130.       112      2- Pipe Roll 72- long

131.       113      Guide Roll 75- long

132.       114      Woolen Roll (Draw Roll ) 72- long

133.       115      Double End Screw

134.       116      Single End Screw

135.       117      Grease Nipple

136.       118      Tie Bar Pin

137.       119      Tie Bar Bracket

138.       120      Plaiting Platform

139.       121      Worm & Worm Wheel with  12 T chain

140.       122      Wheel

141.       123      Woolen cloth
